Martin Chiu 於 2006 年 4 月 13 日 上載
::上班中的紅外線::
::改 Nikon Coolpix 5400 紅外線攝影::
參考過之前同好及外國Website的改法後, 終於下定決心去改, 入左部二手的 Nikon Coolpix 5400 , 貪佢係Prosumer, 同有500 mega pixel , 有 NEF & Tiff Format, 晒相都好D.......
小弟係參照外國Website的改法, 再外加 Hoya R72 IR filter 的 :
外國Website: (可以詳細參照以下改法)
以下是小弟的改裝 step by step~~~
鬆開screws把外殼打開:
![](http://images1.fotop.net/albums/MartinChiu/5400IR/P1010455_640.jpg"><br /><br />
<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010456_640.jpg"><br /><br />
<br /><br />
看到 CCD<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010457_640.jpg"><br /><br />
<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010458_640.jpg"><br /><br />
<br /><br />
用適當厚度的阿加力膠片取代原裝的filter(小弟用鈞刀Cut~~~~)<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010460_640.jpg"><br /><br />
<br /><br />
CCD Part<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010462_640.jpg"><br /><br />
<br /><br />
把Cut好的阿加力膠片及膠邊放到原來位置後重新組裝便可 (阿加力膠片買碎料都是十元八塊)<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010463_640.jpg"><br /><br />
<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010464_640.jpg"><br /><br />
<br /><br />
完成<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010467_640.jpg"><br /><br />
<br /><br />
<img src="http://images1.fotop.net/albums/MartinChiu/5400IR/P1010468_640.jpg"></p> </div>
