16-bit 4 x oversampling digital filter and 2 dac method are adopted.
In addition, focusing on improving the basic performance of the LSI itself, the TDA1541A and SAA7220P/B are named "A version" and installed.
The mechanism uses CDM-1MK2
Specifications
Disc format: CD
Digital converter: 16 bit
CD Mechanism: CDM-1 mk2
Frequency response: 2Hz to 20kHz
Dynamic range: 96dB
Signal to Noise Ratio: 103dB
Channel separation: 100dB
Total harmonic distortion: 0.0015%
Line output: 2V
Dimensions: 462 x 104 x 363mm
Weight: 11.5kg
