PortKeys PT5 II
Screen Size: 5 inches
Resolution: 1920 x 1080 (Full HD)
Brightness: 500 nits
Contrast Ratio: 1000:1
Color Depth: 10-bit (8+2 FRC)
Panel Type: IPS
Video Input/Output: 1 x 4K HDMI Input, 1 x 4K HDMI Output
Audio Output: 3.5mm Headphone Jack
USB-A: For firmware upgrades and loading 3D LUTs
Power Input: 7.4V-24V DC barrel connector
Battery Support: Dual battery plates for Sony NP-F and Canon LP-E6 batteries
Professional Monitoring Tools
Focus Peaking
False Color
Waveform (Luma and RGB)
Histogram
Custom 3D LUT monitoring
Anamorphic De-squeeze
Framing tools (grids, aspect ratio guides)
Design & Features
Weight: Approximately 150g (0.28 lb)
Dimensions: 136 x 72 x 18.3mm
Material: PC (Polycarbonate) and toughened glass
Low Power Consumption: 7W
